| Specifications | Description |
| Standards | IEEE, 802.3, 802.3u, 802.1D, 802.1p, 802.1w (Rapid Spanning Tree), 802.1Q (VLAN), IPv4 (RFC 791), IPv6 (RFC 2460), Routing Information Protocol (RIP) v1 (RFC 1058), RIP v2 (RFC 1723) |
| Ports | LAN, WAN, USB |
| Switch | Power button (on/off) |
| Buttons | Reset |
| Cabling type | Category 5e or better |
| LEDs | Power, VPN, USB, WAN, LAN (ports 1-4) |
| Operating system | Linux |
| Network | |
| Network Protocols | ? Dynamic Host Configuration Protocol (DHCP) server ? Point-to-Point Protocol over Ethernet (PPPoE) ? Point-to-Point Tunneling Protocol (PPTP) ? Layer 2 Tunneling Protocol (L2TP) ? DNS proxy ? DHCP relay agent ? IGMP Proxy and multicast forwarding ? Rapid Spanning Tree Protocol (RSTP) ? Dynamic Domain Name System (TZO, DynDNS, 3322.org, NOIP) ? Network Address Translation (NAT), Port Address Translation (PAT) ? One-to-One NAT ? Port management ? Port mirroring ? Software configurable DMZ to any LAN IP address ? Session Initiation Protocol (SIP) Application Layer Gateways (ALG) |
| LAN | Four (4) 10/100/1000 Mbps Gigabit LAN ports with managed switch |
| WAN | One (1) 10/100/1000 Mbps Gigabit WAN port |
| Routing Protocols | ? Static routing ? Dynamic routing ? RIP v1 and v2 ? Inter-VLAN routing |
| Network Address Translation (NAT) Protocol | Port Address Translation (PAT), Network Address Port Translation (NAPT) |
| VLAN Support | Port-based and 802.1Q tag-based VLANs |
| Number of VLANs | 5 active VLANs (3-4096 range) |
| IPv6 | ? Dual-stack IPv4 and IPv6 ? 6to4 tunneling ? Stateless address auto-configuration ? DHCPv6 Server for IPv6 Clients on LAN ? DHCP v6 client for WAN connectivity ? Internet Control Message Protocol (ICMP) v6 ? Static IPv6 Routing ? Dynamic IPv6 Routing with RIPng |
| Network Edge (DMZ) | Software configurable to any LAN IP address |
| Layer 2 | 802.1Q-based VLANs, 5 active VLANs |
| Security | |
| Firewall | Stateful packet inspection (SPI) firewall, port forwarding and triggering, denial-of-service (DoS) prevention, software-based DMZ DoS attacks prevented: ? SYN Flood? Echo Storm ? ICMP Flood ? UDP Flood ? TCP Flood Block Java, Cookies, ActiveX, HTTP Proxy |
| Access Control | IP access control lists |
| Content Filtering | Static URL blocking or keyword blocking |
| Web filtering | Content filtering that covers more than 27 billion URLs |
| Secure Management | HTTPS, username/password complexity |
| User Privileges | 2 levels of access: admin and guest |
| VPN | |
| Gateway-to-gateway IPsec VPN | 10 gateway-to-gateway IPsec tunnels |
| Client-to-gateway IPsec VPN | 10 client-to-gateway IPsec tunnels using TheGreenBow and ShrewSoft VPN client |
| PPTP VPN | 10 PPTP tunnels for remote client access |
| Encryption | Triple Data Encryption Standard (3DES), Advanced Encryption Standard (AES) |
| Authentication | MD5/SHA1 |
| VPN Pass-through | IPsec/PPTP/Layer 2 Tunneling Protocol (L2TP) pass-through |
| Quality of Service | |
| QoS | ? 802.1p port-based priority on LAN port, application-based priority on WAN port ? 3 queues ? Differentiated Services Code Point support (DSCP) ? Class of Service (CoS) ? Bandwidth Management for service prioritization |
| Jumbo Frame Support | ? Supports Jumbo Frame on Gigabit ports-at least 1536B |
| Performance | |
| NAT Throughput | 800 Mbps |
| Concurrent Sessions | 12,000 |
| IPsec VPN Throughput | 50 Mbps |
| Configuration | |
| Web User Interface | Simple, browser-based configuration (HTTP/HTTPS) |
| Management | |
| Management Protocols | Web browser, Simple Network Management Protocol (SNMP) v3, Bonjour, Universal Plug and Play (UPnP) |
| Event Logging | Local, syslog, email alerts |
| Network Diagnostics | Ping, Traceroute, and DNS Lookup |
| Upgradability | Firmware upgradable through web browser, imported/exported configuration file |
| System Time | Supports NTP, daylight savings, manual entry |
| Languages | GUI supports English, French, Italian, German, and Spanish |
| Environmental | |
| Power | 12V 2A |
| Certifications | FCC class B, CE, IC |
| Operating Temperature | 0° to 40°C (32° to 104°F) |
| Storage Temperature | -20° to 70°C (-4° to 158°F) |
| Operating Humidity | 10 to 85 percent noncondensing |
| Storage Humidity | 5 to 90 percent noncondensing |
Производитель | Cisco |
